Ventilation systems design

Full package of project documentation
Project budgeting
Polnoye sledovaniye dokumentatsii
Elaboration of the project to the smallest details
Automation and integration with other systems

Why are correct climate systems important?

The well-being and health of a person directly depends on the level of comfort in the room. First of all, the parameters of the microclimate have influence on it. If correct temperature, quality and quantity of the air are not maintained in the room, this immediately affects person’s well-being, and later - their health.

Fresh air supply and exhaust air removal
Fresh air supply and exhaust air removal
Preventing the formation of bacteria and germs
Preventing the formation of bacteria and germs
Comfortable temperature and humidity
Comfortable temperature and humidity
Convenient control of climate systems
Convenient control of climate systems

DESIGN IS A MUST

​At first, it may seem that design is a step that can be overlooked and thereby save money. But we are sure that this opinion is wrong, because with it you get a system according to your budget, which works efficiently, it is well placed and works in conjunction with other engineering systems.

WHY DOES THE SYSTEM NEED TO BE DESIGNED BEFORE THE BEGINNING OF REPAIR WORKS?
Kachestvennyy rezultat
QUALITATIVE RESULT

An efficient system that suits all room parameters

Vnedreniye v dizayn interyera
INTEGRATION IN INTERIOR

Aesthetics and productivity of a climate system are result of common work

Soglasovaniye rabot so smezhnymi spetsialistami
AGREEMENT OF ALL WORKS

Interaction with "subcontractors" (installers, builders, electricians)

Integratsiya s drugimi inzhenernymi sistemami
COMPLEX CLIMATIC SYSTEMS

Complex projects for several systems - saving time and nerves

Formirovaniye tochnoy smety byudzheta
FORMING OF BUDGET

The ability to clearly plan the budget for the climate system

​What does the ventilation system project include?

The necessary conditions, during development of the engineering system project, is to provide the customer with the following documents:

  1. Drawing package: ventilation system patterns, plans and sections.
  2. Specifications.
  3. Assignments for workers: electricians, plumbers and builders (if necessary).
  4. Technical and economic feasibility of ventilation equipment selection.
Get an accurate calculation

Send a request and we will contact you in 10 minutes time

Special conditions of cooperation

We are happy to jointly conduct projects with organizations and self-employed specialists, recommend you to our clients and help with the outsourced engineering part. Additionally, we invite you to attend seminars of the "Engineering in Design" series, where we show by examples how to correctly implement engineering systems in the interiors of end customers.

Become a partner
For interior designers
For architects
For foremen
For dealers

STAGES OF IMPLEMENTATION

We have built a process that guarantees the result
  • Consultation
  • Calculation of air exchange
  • Scheme development
  • Preparation and approval of the drawing
  • Preparation of documentation
01
Consultation

Consultation

The first meeting takes place in our showroom and lasts 1-1.5 hours. We discuss your wishes, features of the object and the profitability of a particular solution. We show how the equipment implemented in the office works - you will have a clear idea of the implemented engineering systems, their efficiency and ergonomics.

02
Calculation of air exchange

Calculation of air exchange

Calculation of the required air exchange in accordance with technical conditions, sanitary and building codes.

03
Scheme development

Scheme development

The scheme is used to: - calculate the duct sizing (aerodynamic calculation), - calculate the noise level generated by the ventilation system (acoustic calculation).

04
Preparation and approval of the drawing

Preparation and approval of the drawing

1. Preparation of a drawing, which is given to the customer for approval. 2. Approval of the drawing, as well as the introduction of changes proposed by the customer or his designer.

05
Preparation of documentation

Preparation of documentation

Power supply, construction and plumbing works + Detailing of air ducts

Cost of design

Cost of ventilation design in Alter Air

The cost of such a project depends on many parameters and first of all on type of premises. The price of mechanical ventilation depends on the class of the selected equipment. The ventilation plan is based on the developed concept.

Several options for system implementation

Budget
Salda supply and exhaust units
127 UAH/sq.m.
Medium
Maico supply and exhaust units
127 UAH/sq.m.
Premium
Jablotron supply and exhaust units
127 UAH/sq.m.
Would you like to see the systems?

We invite you to the showroom with the implemented climatic systems. You can take a look and feel the work of ventilation, conditioning and heating systems.

Summaries:

Design and installation of ventilation is a responsible and extremely important factor for organizing comfortable climatic conditions in the house. Your system will work ineffectively in 90 % and will certainly consume a huge amount of electricity, make noise, carry out improper air exchange and, in the most deplorable case, will not work at all without a high-quality and well-designed project. Contact the specialists on the issues relating to engineering systems design to avoid these unpleasant situations and unnecessary financial costs.

In Alter Air company there work professional engineers with long-term experience in this field, so you can safely trust them the issue of ventilation, so that later you can enjoy comfort and cosiness in your home without any problems. The service of ventilation systems design in Kyiv or ventilation design in Kharkiv and in other cities is the specialization of Alter Air company, so they know everything about it! Engineers offer a service on site visits (even to other cities!) or will gladly advise you in the office in Kyiv.

Only the artificial (mechanical) ventilation can be used for optimal air parameters in the room and its operation does not depend on weather conditions and it can carry out air exchange in the room throughout the year in a given volume.

Our projects

Completed objects done for our clients are the best provement of professionalism

Engineering systems in the Alter Air office

  • MEETING ROOM
  • SHOWROOM
VENTILATION UNIT ЈАВLOTRON FUTURA L WITH COOL BREEZE MODULE

Jablotron Futura L is an innovative air handling unit that provides ventilation in a house, apartment or office. Provides fresh filtered air to the premises and removes exhaust air. It is autonomous and intelligent, integrates with the smart home system and is controlled by a mobile application. She herself notifies the owners of the need to replace filters or problems that have arisen. The Jablotron CoolBreeze module (white block on top of the unit) works in conjunction with the Jablotron Futura, cooling or heating the air depending on the season or personal preferences of the owners.

AIR-WATER HEAT PUMP VIESSMANN VITOCAL 100S

Viessmann Vitocal 100-S AWB-M 230V 101.A04 "air-to-water" heat pump is designed to provide heating and hot water supply. Consists of 2 separate blocks - internal (which is located in our office) and external (located on the outer wall of the building) .They are connected to each other by means of freon pipes. Through them the refrigerant (R410A) with a high temperature moves to the indoor unit, giving off heat to the system.

UPONOR DISTRIBUTION COMBO

UPONOR distributor manifolds are a Scandinavian approach to heating. They are an element of underfloor heating and contribute to high-quality and efficient heating of a house or apartment. They are produced for hot and cold water, can be interconnected and completely eliminate the risk of pipe breakage.

PUMP GROUP MEIBES

The Meibes pumping group is used to maintain the temperature and supply water in the heating system. Allows you to accurately control the coolant and adjust its parameters. It is distinguished by high reliability and stability of work, with its help it is easy to control the temperature of the coolant. It integrates into almost any modern heating system, is especially widely used in the "Warm floor" circuit.

PUMP GRUNDFOS UPS 25/6

The circulating pump Grundfos UPS 25/6 is small-sized and practically silent, it is distinguished by economical consumption of electricity. It is used for water circulation in heating systems, including floor heating systems, and hot water supply. The Grundfos UPS 25/6 pump is easy to connect and manually adjust.

UPONOR DISTRIBUTION COMBO

UPONOR distributor manifolds are a Scandinavian approach to heating. They are an element of underfloor heating and contribute to high-quality and efficient heating of a house or apartment. They are produced for hot and cold water, can be interconnected and completely eliminate the risk of pipe breakage.

VAV VALVES ABLOTRON VARIOBREEZE

The Jablotron VarioBreeze is a variable air VAV valve, one of the components of the VAV system. It is a control damper that adjusts the air flow in a particular room - from full air flow to shutting off the air flow. That is, it allows for zone ventilation with variable fresh air supply.

PUMP GROUP MEIBES

The Meibes pumping group is used to maintain the temperature and supply water in the heating system. Allows you to accurately control the coolant and adjust its parameters. It is distinguished by high reliability and stability of work, with its help it is easy to control the temperature of the coolant. It integrates into almost any modern heating system, is especially widely used in the "Warm floor" circuit.

COPPER PIPES OF THE HEATING SYSTEM

When organizing engineering systems, we make all piping of boiler rooms on copper. This material is not afraid of temperature changes, does not lend itself to the negative effects of ultraviolet rays and has a service life of 50 years, which is comparable to the service life of residential buildings. Copper pipes ensure the reliability and durability of the entire system.

EXPANSION TANK ZILMET CAL-PRO 35L

The Zimet CAL-PRO 35L expansion tank is designed to compensate for changes in the volume of water in the heating system. It prevents pressure drops and helps reduce energy consumption. Used in conjunction with boilers and pumps. Tanks of the Zilmet brand are distinguished by their high strength, wear resistance and anti-corrosion properties.

ACCUMULATING TANK DRAZICE UKV 102

Accumulating tank Drazice UKV 102 is designed to accumulate excess heat from the heat generator of the heating system (in our case, a heat pump). It is made of steel, the inner surface remains untreated. Covered with non-removable polyurethane insulation. we give preference to the Drazlce brand for the implementation of systems with heating elements.

SILENCER FOR AIR DUCTS

Silencers for ducts are necessary in order to reduce the noise level. This requirement is especially important in office premises. Silencers are installed in the ducts directly behind the ventilation unit and significantly reduce the noise level in the ventilation ducts. In our projects we use the highest quality sound attenuators of well-known brands, for example, Systemair.

Engineering systems in the Alter Air office

Ventilation, air conditioning and heating in the apartment, residential complex "Novopecherskie Lipki"

  • KITCHEN
  • DINNER ZONE
  • WARDROBE
  • LIVING ROOM
SUPPLY AND EXHAUST GENERAL VENTILATION SYSTEM MAICO Ws 320 KB

Air handling unit Malco WS 320 kV with heat recovery, designed to ensure proper air exchange in a residential or commercial space. In this device, the KB index indicates the presence of a built-in heater and a bypass.

KITCHEN MIXER MOONY

Single lever sink mixer with 28 mm swivel spout, double flow for clean water. The water is turned on and off by means of one chrome-plated lever. Refined design and durable materials will ensure the reliability of the mixer for many years.

DRIVE FOR AIR DAMPER BELIMO

Designed to control air dampers. It can be used in both ventilation and air conditioning systems. The drive has a protective function against frost or smoke.

SALDA SILENCERS SALDA

Silencers are used to reduce sound pressure in circular ventilation ducts. They provide quiet operation of the ventilation unit, they are mounted on each of the air inlets to the ventilation unit. In this case, 4 silencers are provided.

IN-FLOOR CONVECTOR KAMPMANN KATHERM QK

Heat convector Katrtan Katherm QK-high-quality equipment for space heating. It has a function of forced convection (built-in fan), which combines EC-technology of fans together with smooth regulation of its speed (KaControl control system). This solution allows you to increase energy efficiency to the maximum level. It also guarantees a quieter operation without discomfort for the occupants.

TROX CONCEALED LINEAR DIFFUSERS

Trox slot diffusers are used in residential and administrative premises, and are installed in suspended ceilings. The design includes guide vanes (by default - black, on order the color can be different), a plenum box with a branch pipe. These devices are used in supply and EXHAUST ventilation systems. Their advantage is the ability to accurately direct the air flow. Trox slot diffusers are made of high quality aluminum.

DUCT AIR CONDITIONER DAIKIN FDXM25 Daikin

FDXM25-duct-type indoor unit, designed for rooms up to 25 m2 The unit was placed in the ceiling space, making the room visually freer without unnecessary details and equipment. It can work for cooling, heating or dehumidification.

DESIGN RADIATOR ЈAGA STRADA

The Jaga Strada radiators are distinguished by their high thermal performance and stylish design: the heat exchanger maximizes heat production with minimal energy consumption, and the panels, in combination with the stylish grille, give the appliance an elegant look. They can be combined with condensing boilers, react quickly to changes in room temperature.

TROX CONCEALED LINEAR DIFFUSERS

Trox slot diffusers are used in residential and administrative premises, and are installed in suspended ceilings. The design includes guide vanes (by default - black, on order the color can be different), a plenum box with a branch pipe. These devices are used in supply and EXHAUST ventilation systems. Their advantage is the ability to accurately direct the air flow. Trox slot diffusers are made of high quality aluminum.

Ventilation, air conditioning and heating in the apartment, residential complex "Novopecherskie Lipki"

Videoreview of
ventilation systems

Ventilation, air conditioning and heating systems in the interior design - Kiev, RC Novopecherskie Lipki
Ventilation, air conditioning and heating systems in the interior design - Kiev, RC Novopecherskie Lipki
JABLOTRON LIVING TECHNOLOGY - a new word in residential ventilation
JABLOTRON LIVING TECHNOLOGY - a new word in residential ventilation
Ventilation, heating and air dehumidification in a 70 m2 indoor pool, Gostomel
Ventilation, heating and air dehumidification in a 70 m2 indoor pool, Gostomel
Post author
ABOUT COMPANY
Do you want to create a healthy and favorable climate in your home?
You have come to the right place!

We solve the problem of microclimate in a house, starting from ventilation, air conditioning, heating and ending with humidification and air purification. We make sure that all systems interact productively with each other and at the same time do not consume a lot of energy in order to save your costs. In our work, we are like a family doctor - we treat your home, analyze a problem, offer solutions to it, and not just sell pills like a pharmacist in a pharmacy.

More about company

500 useful reviews
2 000 satisfied customers
10 000 items in the store
2 300 commissioned objects

Frequently asked questions

What is natural ventilation and what is it for?

Organized air exchange is the main way to ensure air purity. Previously, automatic exhaust ventilation systems were used in residential construction. The outside air was supplied through leaks in window frames and doors.

The main advantages of such a system are:

  • moderate price;
  • easy handling;
  • minimum of operating expenses.

The disadvantages of the system are:

  • unstable air exchange in the room caused by significant influence of the outdoor climate on the operation of automatic ventilation;
  • insufficient air supply into the dwelling;
  • discomfort from opening windows in the cold season;
  • high energy costs.

In any case, automatic ventilation is not able to fully satisfy the needs for clean air in the room. It does not allow you to create optimal climatic conditions in the room, in which all the family members will feel comfortable.

Mechanical ventilation: advantages and disadvantages

With a mechanical method, air exchange occurs due to the pressure difference created by the ventilation devices. The corresponding set of ventilation equipment, which will be responsible for the planned air exchange, is designed for any type of object. A well-organized mechanical system improves microclimate conditions in the house and makes them comfortable. This way of organizing air exchange is optimal for people who value well-being and care about the health of their families. The automatic ventilation capacity will be insufficient in this case.

The advantages of mechanical ventilation are following:

  • it is carried out with air exchange rate, which was preliminary calculated. The indicators correspond to the norms, the number of people living in the house and the layout of the premises;
  • the supply air is cleaned using the provided filters;
  • there is the ability to adjust the air flow of the entire system;
  • such installations are practically silent due to the constant improvement of production technology and the use of the necessary components (silencers).

Along with the advantages, there are also disadvantages:

  • regular maintenance;
  • timely inspection and cleaning of functional elements;
  • the cost of ventilation works, but in this case, it is worthwhile to understand that the mechanical method provides the necessary level of comfort in the house and creates healthy microclimate conditions.

In turn, mechanical ventilation is divided into exhaust (removes exhaust air) and supply (supplies fresh air). At the place of organization, the system can be local and general exchange.

Industrial ventilation systems design

In this aspect, we consider:

  • semi-industrial (public and administrative buildings such as cinemas, theatres, offices, museums, shopping centres, shops, cafes and restaurants);
  • industrial (storage of products or consumables, plants, factories, industrial complexes, hospitals, research centres and laboratories).

General ventilation systems with heat recovery units are implemented at semi-industrial facilities (according to the State Construction Standards). It is possible to maintain climatic conditions based on humidity by dehumidifying or humidifying the air, for example, in a theatre or museum.

General ventilation in combination with a local supply, local exhaust systems and aspiration can be organized at industrial facilities. The latter system is used in industrial (paint and varnish, woodworking) workshops, where it is necessary to remove small particles of pollution from the air.

The main difference between the systems under consideration at industrial facilities in comparison with household facilities is the organization of local exhaust and supply ventilation, as well as aspiration and pneumatic transport systems and the use of specialized equipment.

The local exhaust system involves the installation of a hazard detector (lateral exhaust, exhaust hood) near the area where harmful substances (fine dust, etc.) are emitted, which must be removed.

Local cooling is intended for premises, the climatic conditions of which do not allow the personnel to work fully. To avoid this, the supply of the normalized amount of air necessary for human life and work is provided directly to the workplace.

The aspiration and pneumatic transport system is the removal of contaminants and industrial waste in the form of dust, shavings, paint and varnish waste together with air through specially equipped main air ducts. This action is carried out with special equipment and undergoes a special purification before being discharged into the atmosphere.

Get a ventilation system design

Take care of the health and comfort of our family
